SZGH-13100CC 1000W SERVO MOTOR
Item NO: SZGH-13100CC
Minimum Order: 1 Set
Package: canton
Place Of Origin: Shenzhen,China
Skype Me!
Overview:
SZGH-13100CC is 1000W ,4NM and 2500RPM servo motor, it is low cost , and very general-purpose type. Imported feedback components, original imported low-noise motor .
Specs
1) 800x600 8.4 inch real color LCD displayer.
2) Support PLC and macro function, and automatic tool exchange function .
3) 128Mb user store room, 2-channel analog
4) 32 input, and 32 output.
5) Touch screen main and sub panel.
6) High anti-jamming switch power.
7) USB movable U disc copy interface.
8) RS232 interface.
9) Spindle servo speed control/spindle frequency convenient speed control.
10) Max screw processing thread pitch is 1000MM
11) 32 bits high performance, low power consumption industrial grade ARM11 microprocessor.
12) C cutter offset function and binary encode tool .
13) support the customized' application solution by client' logo and company name
System constructions:
32 bits high performance, low power consumption industrial grade ARM11 microprocessor.
128MB memory, 100Mb user store room.
800x600 8.4 inch real colour LCD displayer.
Touch screen main and sub panel.
High anti-jamming switch power.
USB movable U disc copy interface.
RS232 interface.
Spindle servo speed control/spindle frequency convertion speed control.
Manual pulse generator.
System technical parameter:
controllable axes:X,Z,C/Y A B 5 axes.
linkage axes:Arc 3 axes, liner 5 axes.
pulse equivalent:X,Z,C/Y,A,B axes:0.001mm.
max speed:X,Z,C/Y,A,B:60000mm/min.
cutting speed:1-10000mm/min.
min input unit:0.001mm.
program size range:± 99999.999.
99 tools management.
controllable liner vertical type or revolving disc type tool changer.
program code:ISO-840 international standard.
program coordinate system definition:ISO-841.
chassis protection complies with regulation of IP43.
System function:
1.Auto-diagnosis function
All around diagnosis of CPU, storer, LCD, I/O interface, parameter status, coordinates, machining program etc. shall execute when the system starts or resets. In operation, it makes real time diagnosis of power, spindle, limit and all I/O interface.
2. Compensation function
automatic backlash compensation.
tool radius automatic compensation.
tool radius automatic offset and sharp angle transition.
leading screw pitch error automatic compensation.
3 .Abundant instruction system
scaling up/down instruction.
mirror machining instruction.
mutiple tool offset instruction.
program cycle, jump, call and different program ending.
multiple positioning instruction:starting point,setting fixed point,etc.
linera, circular,spiral line interpolation instruction.
program management instructions: program cycle, call, transfer and different program ending method, etc.
6 workpeices coordinates system .
